Mute SG-Ready Wifi Solar Hybrid Heating COP6.0 EER4.0 A+++ 22kw R32 Air Chilled Room Heated Tap Hot Water Split All-in-One EVI DC Converter Air to Water Heater Pump Boiler
Mute SG-Ready Wifi Solar Hybrid Heating COP6.0 EER4.0 A+++ 12-22kw R32 Air Chilled Room Heated Tap Hot Water Split All-in-One EVI DC Converter Air to Water Heater Pump Boiler
- 5 years warranty
- Heating+Cooling+DHW
- SG Ready function
- Energy class A+++ / A++
- Noise in 1M ≤56dB
- Application for remote control of the pump for Android or iOS
- Water outlet temperature up to 60 degrees
- R32(high performance and low environmental impact)
Quote Now
1. Top SCOP in cold, ENERGY SAVING in homeothermy, DC Inverter Dual Rotary compressor and ECO R32 gas for max heat capacity and less gas, large volume of latent heat, even when air temperature is -35℃.
2. Ultra frequency conversion technology, mainly drive variable frequency by way of PWM synthesis. It fully integrate power, electronics, micro-PC system and other technologies.
3. PUNP Advanced Operate System, constantly stable, ultra intelligent, simple click and fully play the characteristics of DC inverter frequency conversion system to achieve overlocking performance. CAREL Operating System is capacity if it’s requested.
4. DC mute fan motor, streamline fan blades, ultra-low noise, durable & reliable, constant max air flow to satisfy enregy supply.
5. Classical European image, 3-color housing, fashion taste, never out of time.
6. WIFI remote control, free of distance, your warm care to all your famlies, always with sweet face~
7. Flate type expansion tank and Wilo water pump are built in indoor unit, saving plenty of labor force when installing and maintaining. Mostly decreases runing noise, leaving a quiet enough living environment for the whole families.
8. Split design, easily to be frozen and crack key parts to protect well indoor intalling, especially when air temperature below -10DegC, exceeding -.
9. Touch Screen Operate Panel, 12 Languages are optional.
Item No. | ADC-16HC(S) | ADC-20HC(S) | ADC-22HC(S) | ||
HP | 5HP | 6HP | 7HP | ||
Power Supply | 220-240V/50-60Hz/1ph or 380-415V/50-60Hz/3ph | ||||
Heating Condition： Ambient Temp. +7℃/+6℃(WB/DB), Water Temp. +30℃/+35℃(In/Out). | |||||
Heating Capacity Rang | kW | 3.73-12.75 | 4.81-16.05 | 6.24-18.85 | |
Power Input Range | kW | 0.58-2.83 | 0.78-3.7 | 0.96-4.08 | |
Hot Water Condition: Ambient Temp. +20℃/+15℃(DB/WB), Water Temp. +15℃/+55℃ (In/Out). | |||||
Heating Capacity Rang | kW | 4.14-15.97 | 5.35-19.25 | 6.74-22.66 | |
Power Input Range | kW | 0.88-3.21 | 1.06-3.98 | 1.33-4.67 | |
SCOP | at 35℃ water outlet | 5.08 | 5.1 | 5.1 | |
at 55℃ water outlet | 4.86 | 4.84 | 4.84 | ||
ErP Level | at 35℃ water outlet | A+++ | A+++ | A+++ | |
at 55℃ water outlet | A++ | A++ | A++ | ||
Heating operation range | Ambient | °C | -30~25 | ||
Heating side | °C | 18~60 | |||
Domestic hot water operation range | Ambient | °C | -30 ~ 43 | ||
Water side | °C | 25~60 | |||
Chilling Condition： Ambient Temp.35℃/30℃ (DB/WB), Water Temp.12℃/7℃(In/Out). | |||||
Chilling capacity | kW | 2.35-10.92 | 3.24-13.37 | 4.37-15.95 | |
Power input range | kW | 1.06-3.84 | 1.38-4.67 | 1.57-5.46 | |
Chilling operation range | Ambient | °C | 10~43 | ||
Water side | °C | 7~22 | |||
Rated water flow rate | m³/h | 2.4 | 2.75 | ||
Rated pressure drop | kPa | 30 | 45 | 45 | |
Max. working pressure | Refrigerant | Bar | 44 | 44 | 44 |
Water | Bar | 7 | 7 | 7 | |
Controller | SumAir Micro processor, digital wire controller, LCD Touch Screen | ||||
External cabinet | Galvanized steel with powder coating | ||||
Compressor | Type | Panasonic Dual Rotary | |||
Refrigerant | R32 | ||||
Water heat exchanger | SUS 316 Brazed plate heat exchanger | ||||
Circulation pump | DAB/WILO/DANFOSS | ||||
Expansion Tank | 6L | 6L | 6L | ||
Water pipe | Inlet&Outlet | DN | 25 | 25 | 25 |
Noise in 1Mtr | Indoor Unit | dB(A) | ≤30 | ≤31 | ≤31 |
Outdoor Unit | dB(A) | ≤52 | ≤56 | ≤58 | |
Unit size (W*D*H) | Indoor Unit | mm | 550*160*650 | 550*160*650 | 550*160*650 |
Outdoor Unit | mm | 1080*470*1400 | 1080*470*1400 | 1080*470*1400 | |
Packing size (W*D*H) | Indoor Unit | mm | 650*260*750 | 650*260*750 | 650*260*750 |
Outdoor Unit | mm | 1180*570*1500 | 1180*570*1500 | 1180*570*1500 | |
N.W. | Indoor/Outdoor | kg | 55/85 | 55/90 | 55/100 |
G.W. | Indoor/Outdoor | kg | 60/95 | 60/100 | 60/110 |
Product Apperance
Detailed Image of DC Inverter Heat Pump Water Heater
SG ready Certificates
SG-Ready Installing/Control Logic
Installation Cases of Mute SG-Ready Wifi Solar Hybrid Heating COP6.0 EER4.0 A+++ 12-22kw R32 Air Chilled Room Heated Tap Hot Water Split All-in-One EVI DC Converter Air to Water Heater Pump Boiler
